Induct 2000
The activTek INDUCT 2000 with revolutionary ActivePure® technology can be a major improvement for your typical HVAC system, since it capable not only of eliminating odors and visible smoke, but also removing harmful contamination on surfaces. The INDUCT 2000 has two installation options: for 100 or 277 volts. This unit can be mounted in a ductwork or plenum for significant increase of air quality. Based on the principle «install it and forget», The INDUCT 2000 does not need specific treatment or scheduled cleaning. This unit has a helpful indicator using a UV bulb. It is recommended for working spaces ~2000 square feet.
Note: we recommend hiring a qualified HVAC professional to install this unit.
Installation:
Standard INDUCT Installation
• Allows wiring into a 100 or 277 volt connection.
• Quick installation with the help of 4 mounting holes in chassis. Having several units in one plenum area won’t be a problem as the installation can be easily shifted so all units incur direct air flow.
• Before conducting the installation procedure cut an orifice (4" or 10.16 cm) in the ductwork to prevent any complications during the process.
• Be sure to install the unit right after the main air handler in the HVAC system.
• Wipe the installation area clean and let it dry for best conglutination of the gasket materials and tape.
Specifications:
|
electrical |
100/277 VAC, 50/60 Hz | .17A 19 watts |
|
mechanical |
UV bulb monitoring system installed | Safety interlock switch installed |
|
dimensions |
9.62"H x 9.62"W X 11.25" D | 24cm L x 24.5cm W x 28.5cm D |
|
weight |
3 pound | 1.2 kilograms |
|
coverage |
up to 2000 square feet |
|
max temp |
<200°F |
|
warranty |
1 year |
